HM500
Low Frequency Driver
2 Inches
HOME
Voice Coil Diameter
50 mm 2 in
Continuous Power Handling
200 W
Sensitivity
91 dB
Voice Coil Diameter
50 mm 2 in
Continuous Power Handling
200 W
Sensitivity
91 dB
Specifications
Nominal Diameter
50 mm (2 in)
Nominal Power Handling
100 W
Sensitivity
91 dB
Voice Coil Diameter
50 mm (2 in)
Magnetic Gap Depth
3 mm (0.12 in)
Nominal Impedance
8 Ω
Continuous Power Handling
200 W
Frequency Range
700 Hz - 700 Hz
Winding Depth
3.5 mm (0.14 in)
Parameters
Fs
550 Hz
Qes
0.8
Qts
0.66
Xmax
1 mm (0.04 in)
Bl
7.5 Tm
d
58 mm (2.28 in)
Re
6.5 Ω
Qms
3.8
Sd
26 cm² (4.03 in²)
Mms
2 g
Le
0.2 mH
EBP
688 Hz
Design
Cone Shape
Dome
Mounting and Shipping Info
Overall Diameter
130 mm (5.12 in)
Baffle Cutout Diameter
103 mm (4.06 in)
Flange and Gasket Thickness
5 mm (0.2 in)
Shipping Units
6 pcs
Bolt Quantity
4 pcs
Bolt Circle Diameter
116 mm (4.57 in)
Depth
45 mm (1.77 in)
Net Weight
1.5 kg (3.3 lb)
Basket Material
Plastic Flange
Bolt Diameter
5 mm (0.2 in)
