CX131
Coaxial
5 Inches
CAR
Voice Coil Diameter
25 mm 1 in
Voice Coil Diameter
25 mm 1 in
Continuous Power Handling
150 W
Continuous Power Handling
150 W
Voice Coil Diameter
25 mm 1 in
Voice Coil Diameter
25 mm 1 in
Continuous Power Handling
150 W
Continuous Power Handling
150 W
Specifications LF unit
Nominal Diameter
130 mm (5 in)
Nominal Power Handling
60 W
Sensitivity
89 dB
Former Material
Aluminum
Magnetic Gap Depth
4 mm (0.16 in)
Nominal Impedance
4 Ω
Continuous Power Handling
150 W
Voice Coil Diameter
25 mm (1 in)
Winding Depth
9 mm (0.35 in)
Specifications HF unit
Nominal Diameter
130 mm (5 in)
Nominal Power Handling
60 W
Sensitivity
89 dB
Winding Depth
9 mm (0.35 in)
Nominal Impedance
4 Ω
Continuous Power Handling
150 W
Voice Coil Diameter
25 mm (1 in)
Design
Surround Shape
Polyurethane
Parameters
Fs
83 Hz
Qes
0.49
Qts
0.43
Sd
88 cm² (13.64 in²)
Xmax
3.5 mm (0.14 in)
Bl
4.59 Tm
d
106 mm (4.17 in)
Re
3.4 Ω
Qms
3.45
Vas
6.8 dm³ (0.24 ft³)
η0
0.76 %
Mms
5.9 g
Cms
0.62 mm/N
EBP
169 Hz
Mounting and Shipping Info
Overall Diameter
129.5 mm (5.1 in)
Baffle Cutout Diameter
112 mm (4.41 in)
Flange and Gasket Thickness
8 mm (0.31 in)
Shipping Units
6 pcs
Bolt Quantity
4 pcs
Bolt Circle Diameter
149 mm (5.87 in)
Depth
64.5 mm (2.54 in)
Net Weight
0.98 kg (2.16 lb)
Basket Material
Steel
Bolt Diameter
5 mm (0.2 in)
